SQ 4kW/6kW-LV-1P Ecco

Single Phase | IP20

The SQ 4kW/6kW-LV-1P Ecco single-phase storage inverter is tailored for residential storage systems, providing exceptional efficiency, safety, and stability. Featured with easy-to-install, user-friendly, and suitable for diverse home environments, it is the ideal choice for economical off-grid storage solutions.

Datasheet

High Efficiency

Max. efficiency up to 97.6%.
High battery input current up to 130A.
Zero export control to make full use of PV power.
Stronger Compatibility & Stability

Compatible with Li-ion and Lead-acid batteries.
UPS 10ms switching time for seamless power continuity.

Easy Installation

Opened front panel for wiring.
Small in size, light in weight.
User-friendly Touchscreen Interface

User-friendly segment display interface and operation buttons.
Free IP41 magnetic dust cover.

Basic Parameter

- Max. DC input power:

  4500W / 8000W
- Max. input current:

  15A / 30A
- Max. output power:

  4kW / 6kW
- Battery input voltage range:

  40~60V
- Battery capacity (Recommend):

  70~1000 Ah / 100~2000 Ah
- Supported battery type:

  Li-lon or Lead-acid
- Nominal battery voltage:

  48V
- Shift time (Bypass and inverter):

  10ms
- Max. efficiency:

  97.6%
- Battery Communication

  CAN
- Monitoring

  WIFI / Bluetooth

Where You Need Them

Home Energy Storage
Off-Grid PV Storage System
Optimize Solar and Energy Use
Backup Power

Intelligent Control & Monitoring

Multiple operating modes to optimize energy utilization based on real-time conditions. Remote real-time monitoring capabilities via WiFi/Bluetooth for convenient oversight and control.
